1985 Ford Escort, EXP / Mercury Lynx Electrical & Vacuum Troubleshooting Manual

Covering the following:

• 1985 Ford Escort L, Escort GL, Escort LX, Escort GLS & Escort GT
• 1985 Ford EXP Base, EXP Luxury, EXP Turbo
• 1985 Mercury Lynx Base, Lynx L, Lynx GL, Lynx GS, & Lynx XR3
• Coupe, Hatchback & Wagon
• 1.6L Gas & 2.0L Diesel Engines

11" x 8.5" x .3" | Approx. 130 pages | Published by the Ford Motor Company

Connector Configurations * Harness Locations * Circuits * Relays * Grounds * Vacuum Diagrams * Valve & Sensor Locations * Hose Colors * Vacuum Distribution * Wiring Diagrams

This is the Official Manual of the dealerships, written by Ford specifically for the vehicle(s) listed. This ensures you get the job done right the first time. It is very detailed with good diagrams and exploded views. A must for anyone who insists on Genuine OEM quality parts.

Condition

Good condition. Covers show light wear. All pages are in place and straight. Page surfaces are mostly clean.

Topics Include

• General Information
• Grounds
• Fuse Panel/Circuit Protection
• Charging System
• Power Distribution
• Communication Network
• Wiring Diagrams
• Component Testing
• Connector Faces
• Component Location Views
• Harnessing
• Vehicle Repair Location Codes
