1989 Suzuki Motorcycle and ATV Electrical Wiring Diagrams Manual 89 Year Code K

1989 Suzuki Motorcycle and ATV Wiring Diagrams

This manual is intended to aid Suzuki dealers in tracing wiring circuits and troubleshooting electronics on 1989 Suzuki K model motorcycles. These wiring diagrams are for Suzuki motorcycles distributed in the United States and Canada. You will know yours is a 1989 Model if the last letter of your model number is an K.

Each model will have one page dedicated to its wiring circuit and wiring diagrams. Although the schematic is in black and white, the color of each wire is noted

Published in 1989 by the American Suzuki Motor Corporation

Condition

Good to very good condition. Covers show light wear. Page surfaces are in place and straight. Page surfaces are clean.

Models Covered

FA50K
JR50K
DS80K
DR100K
RMX250K
GS500EK
VS750GLK
GSX600FK
GSX750FK
GSX1100FK
GSX-R750K
GSX-R1100K
LT80K
LT160EK
LT230EK
LT250SK
LT300EK
LT-F250K
LT-4WDK
LT250RK
LT500RK
