2013 Expedition / Navigator Wiring Diagrams

Covering all including the following:

• 2013 Ford Expedition XL, EL XL, XLT, EL XLT, Limited, EL Limited, Max Limited, King Ranch & EL King Ranch
• 2013 Lincoln Navigator Base, Limited, Ultimate, L, L Ultimate, L Executive

11" x 8.5" x .8" | Approximately 450 pages | Published by the Ford Motor Company

Covering Schematics * Fuse Panel/Circuit Protection * Charging System * Power Distribution * Wiring Diagrams * Component Testing * Connector Faces * Component Location Views * Harnessing * Vehicle Repair Location Codes

This is the Official Manual of the dealerships, written by Ford specifically for the vehicle(s) listed. This ensures you get the job done right the first time. It is very detailed with good diagrams and exploded views. A must for anyone who insists on Genuine OEM quality parts.

Condition

Very good condition. Covers are clean. All pages are in place and straight. Page surfaces are clean.

Topics Include

• General Information
• Grounds
• Fuse Panel/Circuit Protection
• Charging System
• Power Distribution
• Communication Network
• Wiring Diagrams
• Component Testing
• Connector Faces
• Component Location Views
• Harnessing
• Vehicle Repair Location Codes
