1987 Ford Taurus Mercury Sable Large Format Electrical Wiring Diagrams

1987 Taurus/Sable Wiring Diagrams

Providing Vacuum and Wiring Schematics for the following:

• 1987 Ford Taurus Base, Taurus L, Taurus GL, Taurus LX & Taurus MT5
• 1987 Mercury Sable GS & Sable LS

(29) - 17" x 11" pages that fold out to 11" x 27" each | Published by the Ford Motor Company

Connector Configurations * Circuit Identification and Location * Relays * Grounds * Wiring Diagrams * Color Coded in Black and White

This is the Original Wiring Diagram written by Ford specifically for the vehicle(s) listed. This ensures you get the job done right the first time. A must for anyone who insists on Genuine OEM quality parts.

Condition

Very good condition. All pages are in place and straight. Page surfaces are clean.
