1990 Ford Thunderbird Mercury Cougar Electrical & Vacuum Troubleshooting Manual

1990 Ford Thunderbird / Mercury Cougar Electrical & Vacuum Troubleshooting Manual

Providing Electrical Troubleshooting and Schematics for the following:

• 1990 Ford Thunderbird Base, LX & SC
• 1990 Mercury Cougar LS & XR7

Original Publication | 11" x 8.5" x .75" | Approximately 400 pages | Published by the Ford Motor Company

Connector Configurations * Harness Locations * Circuits * Relays * Grounds * Vacuum Diagrams * Valve & Sensor Locations * Hose Colors * Vacuum Distribution * Wiring Diagrams

This book was written by Ford specifically for the vehicle(s) listed. It contains Diagnostic Information and Procedures, Schematics and Routing Diagrams, Component Locator, Description and Operation, Specifications, Special Tools and Equipment. A must for anyone who insists on Genuine OEM quality parts.

Condition

Good usable condition. Covers show light wear and soiling. All pages are in place and straight. Page surfaces are mostly clean.

Topics Include

• General Information
• Grounds
• Fuse Panel/Circuit Protection
• Charging System
• Power Distribution
• Communication Network
• Wiring Diagrams
• Component Testing
• Connector Faces
• Component Location Views
• Harnessing
• Vehicle Repair Location Codes
