1992 Nissan Truck and Pathfinder Wiring Diagrams

All Including D21 Pickup Base & D21 Pickup SE / Pathfinder Base, Pathfinder XE & Pathfinder SE | 2.4L I4 (KA24E) & 3.0L (VG30E) V6 Engines | Model D21 Series

Published by the Nissan Motor Company

Harness Routing Views * Circuit Diagrams * Connectors * Component Locator Views * Wiring Diagrams

This factory manual is written by Nissan specifically for the vehicle(s) listed. This ensures you get the job done right the first time. It is very detailed with good diagrams and exploded views. A must for anyone who insists on Genuine OEM quality parts.
Large format 11" x 17".

Condition

Good to very good condition. Covers show light wear. All pages are in place and straight. Page surfaces are clean.
