2004 Mazda Pickup Truck B2300 B3000 B4000 Electrical Wiring Diagrams Shop Manual

(No reviews yet) Write a Review
SKU:
999995020G04
Availability:
Usually Ships With 24 Hours
$49.95

Out of stock

Frequently bought together:

Description

2004 Mazda B-Series Truck | Electrical Wiring Diagrams

B2300, B3000 & B4000 Pickups | 2WD & 4WD | All Trims Including Base, DS & SE | 2.3L I4, 3.0L V6 & 4.0L V6 Engines

Part No. 9999-95-020G-04 | Mazda Motor Corporation


OOfficial Manual of the Dealerships.

This is the Official Manual that the dealers and shops use. This is the real thing, written by the manufacturer for their service technicians specifically for the vehicle(s) listed. This ensures you get the job done right the first time. This manual contains Complete Wiring Diagrams for the model(s) listed above including Schematics and Routing Diagrams. This book is very detailed with large color diagrams and well labeled schematics. A must for anyone who insists on Genuine OEM quality parts. Approx. 200 pages.

Condition

Good condition (as pictured). Covers show wear. All pages are in place and straight. Page surfaces are clean.

Topics Include:

  • Introduction
  • How to Use the Manual
  • Troubleshooting
  • Abbreviations
  • Glossary of Terms and Symbols
  • Relay Locations
  • Electrical Wiring Routing
  • Power Source (Current Flow Chart)
  • System Circuits
  • Ground Points
  • Overall Wiring Diagrams
  • Connector Part Numbers

2004 Mazda B-Series Truck B2300 B3000 B4000 Electrical Wiring Diagrams
