2010 Ford Escape and Mercury Mariner Electrical Wiring Diagrams

All Gas Models Including Escape XLS, XLT & Limited/ Mariner Base & Premier | 2.5L I4 & 3.0L V6 Gasoline & Flex Fuel Engines

Gasoline & E85 Flex Fuel Models Only | Ford Motor Company

Covering Schematics * Troubleshooting * Relay Locations * Routing * Flow Charts * System Circuits * Ground Points * Connector Part Numbers * Overall Wiring Diagrams

This is the Official Manual of the dealerships, written by Ford specifically for the vehicle(s) listed. This ensures you get the job done right the first time. It is very detailed with good diagrams and exploded views. It is the best money can buy and a must for anyone who insists on Genuine OEM quality parts.
11" x 8.5" x .5". Approx. 250 pages.

Available Conditions

• Good condition. Covers show light soiling. All pages are in place and straight. Page surfaces are mostly clean.
• Good usable condition. Covers show heavier soiling. All pages are in place and straight. Page surfaces are mostly clean.

Topics Include

• Connector Repair Procedures
• Systems Overview
• Wiring Harness Overview
• Ground distribution
• Fuse and Relay Information
• Charging System
• Power Distribution
• Module Communications Network
• Component Testing
• Connector Views
• Component Location Views
• Component Location Charts
• Vehicle Repair Location Chart
