2016 Ford Transit Electrical Wiring Diagrams

All Transit Van Models Including Cargo Van, XL Passenger Van/Wagon & XLT Passenger Van/Wagon | Low, Medium & High Roof | Regular, Long & Extended | 3.7L V6 and 3.5L EcoBoost V6 Gas & 3.2L I5 Diesel Engines | *NOTE: Does Not Cover Transit Connect

Published by the Ford Motor Company

Covering Schematics * Fuse Panel/Circuit Protection * Charging System * Power Distribution * Wiring Diagrams * Component Testing * Connector Faces * Component Location Views * Harnessing * Vehicle Repair Location Codes

This is the Official Manual of the dealerships, written by Ford specifically for the vehicle(s) listed. This ensures you get the job done right the first time. It is very detailed with good diagrams and exploded views. A must for anyone who insists on Genuine OEM quality parts.
11" x 8.5" x .1.4". Approx. 750 pages.

Condition

Very good condition. Covers show little wear. All pages are in place and straight. Page surfaces are clean.

Topics Include:

• General Information
• Grounds
• Fuse Panel/Circuit Protection
• Charging System
• Power Distribution
• Communication Network
• Wiring Diagrams
• Component Testing
• Connector Faces
• Component Location Views
• Harnessing
• Vehicle Repair Location Codes
