1988 Ford Ranger and Bronco II Electrical & Vacuum Troubleshooting Wiring Manual

1988 Ford Ranger/Bronco II Electrical & Vacuum Troubleshooting Manual

Providing Electrical Troubleshooting and Schematics for the following:

• 1988 Ford Ranger S, STX, Custom, GT & XLT - Standard & Extended Cabs - Short & Long Beds
• 1988 Ford Bronco II XL, XLT & Eddie Bauer

Original Publication | 11" x 8.5" x .35" | 137 pages | Published by the Ford Motor Company

Covering Diagnostic Procedures * Component Testing * Schematics and Routing Diagrams * Fuse and Relay Information * Power Distribution * Vehicle Repair Location Chart * Wiring Diagrams

This book was written by Ford specifically for the vehicle(s) listed. It contains Diagnostic Information and Procedures, Schematics and Routing Diagrams, Component Locator, Description and Operation, Specifications, Special Tools and Equipment. A must for anyone who insists on Genuine OEM quality parts.

Topics Include

• Connector Repair Procedures
• Systems Overview
• Wiring Harness Overview
• Ground Distribution
• Fuse and Relay Information
• Charging System
• Power Distribution
• Module Communications Network
• Component Testing
• Connector Views
• Component Location Views
• Component Location Charts
• Vehicle Repair Location Charts

Condition

Good condition. Covers show some wear. All pages are in place and straight. Page surfaces are mostly clean.
