1988 Ford Ranger and Bronco II Large Format Wiring Diagrams Original

1988 Ford Ranger/Bronco II Wiring Diagrams

Providing Wiring Schematics for the following:

• 1988 Ford Ranger S, STX, Custom, GT & XLT - Standard & Extended Cabs - Short & Long Beds
• 1988 Ford Bronco II XL, XLT & Eddie Bauer

(13) - 17" x 11" pages that fold out to 11" x 27" each | Published by the Ford Motor Company

Connector Configurations * Circuit Identification and Location * Relays * Grounds * Wiring Diagrams * Color Coded in Black and White

This is the Original Wiring Diagram written by Ford specifically for the vehicle(s) listed. This ensures you get the job done right the first time. A must for anyone who insists on Genuine OEM quality parts.

Condition

Very good condition. All pages are in place and straight. Page surfaces are clean.
